Description
UHD 4K playback and recording at up to 60p is introduced with the Blackmagic Design HyperDeck Studio 12G. This file-based deck provides the familiar jog/shuttle interface of traditional VTRs, but instead of tape use SSD drives for recording media. It records in uncompressed QuickTime, ProRes, or Avid DNxHD formats all with up to 4:2:2 color sampling at 10-bit color space. With two SSD slots, you can record almost endlessly – as one SSD becomes full, recording automatically continues on to the other. The Studio 12G features one 12G-SDI input that is 3G-, HD-, and SD-SDI compatible along with one HDMI 2.0 input. In addition, there are four total SDI outputs and one HDMI 2.0 output for monitoring and connection to other equipment in your studio. All of the SDI connectors plus both of the HDMI ports support UHD 4K (3840 x 2160) at up to 60 fps.
The Blackmagic Design Hyperdeck Studio 12G is housed in a 1RU rackmountable unit, with built-in rackmount ears. It features illuminated front panel button control and a jog/shuttle wheel for analog scrubbing. RS-422 control is supported for external control. You can also control the unit using either the USB port or over Ethernet via the RJ-45 connector. An integrated LCD on the front panel allows you to monitor the video, and display timecode and transport information.
When you need to go beyond 1080p30, HyperDeck Studio 12G is a more advanced version of HyperDeck Studio. Featuring 12G-SDI connections and HDMI 2.0, HyperDeck Studio 12G works with all SD, HD and Ultra HD formats up to 2160p60 over a single cable. You still get all of the benefits of HyperDeck Studio, including its familiar VTR style deck controls and broadcast quality compressed and uncompressed 10-bit 4:2:2 recording.
The HypeDeck Studio 12G records video to uncompressed QuickTime at 10-bit with 4:2:2 color sampling at up to UHD 4K (3840 x 2160) at 60 fps. It also records to ProRes 422(HQ), ProRes 422, ProRes 422 (LT), ProRes 422 (Proxy), as well as Avid DNxHD and Avid DNxHD MXF, also all in SD and SD
For accepting storage media, the unit incorporates two 2.5″ slots with SATA connectors for use with SSD drives. The ability to swap out drives while recording enables almost endlessly durations, seamlessly switching from one SSD to the other as the first one fills up.
