Description
Cuescript CSTM19 19″ ‘on-air’ Talent Monitor. In recent years the introduction of talent monitors hung under the prompter has become increasingly popular, tidying up the studio floor and preventing the talent having to look off camera.
Cuescript CSTM19 19″ ‘on-air’ Talent Monitors have been built for purpose and have an aesthetically pleasing curved design. Integrated mounting rails allow for smooth, quick setup and power to the talent monitor can be taken from all the CSM prompters.
The CSTMM* Talent Monitor Mount fits the CSTM19 to all CueScript CSM Monitors.
(*CSTMM mount sold separately.)
Technical Specification:
CSTM19 – 19″ Talent Monitor
- Screen Size: 18.9″ diagonal
- Display Area: 408.24mm(H) x 255.15mm(V)
- Brightness: 1000 cd/m
- Contrast Ratio: 1000:1
- Native Resolution: 1440 x 900 (WXGA)
- Viewing Angle: 170°(H), 160°(V)
- Backlight Technology: LED
DIMENSIONS
- Height: 12.75″ (324mm)
- Width: 18.25” (464mm)
- Depth: 1.9″ (48mm)
- Weight: 8.5lbs/3.8kg
VIDEO
- Autosensing PAL/NTSC/VGA/HD/HD-SDI
- Composite 75 Ohms
POWER INPUTS & CONNECTORS
- XLR 4pin 12V DC
CERTIFICATIONS
- CE, TUV, FCC, C-Tick, PSE, RoHs
MOUNTING
- Slides into the CueScript CSM monitor range via integrated rails using the CSTMM mount.
Can attach to the CueScript EMC Monitor range with a modification.
