Description
The Panasonic AV-HS6000 2ME, 32 Input, 16 Output Live Switcher with complete system adaptability, intuitive operations, high reliability, and advanced 4K compatibility.
Panasonic AV-HS6000 2ME Live Switcher is an open box unit with full warranty. This switcher has the AV-HS60C2 Long Control Panel.
This configuration of the Panasonic AV-HS6000 2 M/E Switcher includes the main frame of the switcher, featuring the input/output connectors and processing engine, and a 2 M/E control panel, both in a dual redundant power supply configuration.
The main frame offers 32 HD-SDI inputs, two DVI-D inputs for incorporating computer sources, and 16 output channels each mirrored on two SDI outputs. The main frame supports video resolutions up to 1080p at 10-bit 4:2:2 in YUV color space, and up to 1080p 8-bit 4:4:4 in RGB color space. It also accepts VESA resolutions up to 1600 x 1200 for a 4:3 aspect ratio output and 1920 x 1200 for a 16:10 output.
The control panel features two sets of bus selector buttons, crosspoint buttons, T-bars, a joystick, transition keys, display panel, and more. It also additionally supports the optional AV‑HS60C3G touchscreen menu panel, which allows quick menu operation as well as control of other functions via physical buttons and rotary encoders.
The AV-HS60U2P Main Frame w/ Dual Power Supply for AV-HS6000 Switcher from Panasonic features the input and output connectors and processing engine that drives the AV-HS6000 2 M/E switcher. It features 32 HD-SDI inputs, along with two DVI-D (digital only) inputs for incorporating content from computer sources. It will support video resolutions up to 1080p at 10-bit, 4:2:2 in YUV color space, and up to 1080p 8-bit, 4:4:4 in RGB color space. Additionally, it will accept VESA computer resolutions up to 1600 x 1200 for 4:3 and 1920 x 1200 for 16:10.
It features 16 output channels, with each output channel mirrored on two SDI outputs. Not only can these outputs be used for an isolated, program, or aux feed, it is also possible to combine up to 16 ISO channels and send to one display using the MultiView function. Additional display arrangements are also possible, including a “squeeze mode” which reduces the image size to fit audio levels and other data around the outside. A total of 4 channels may be used in conjunction with the MultiView function.
The system features two mix and effects (M/E) buses with fades, transitions, and other effects possible. Additionally, the switcher features both upstream and downstream keyers (USK and DSK) for filling in black space, logo and graphic insertion, and compositing. Frequently used effects, setting, video clips, and still images can be save to the internal memory for later recall during a production.
The AV-HS60U2P is designed to be operated using the AV-HS60C1P/AV-HS60C1E or RAV-HS60C2P/AV-HS60C2E control panel. In addition, software plug-ins allow operation over an IP network or using certain Panasonic and third-party RS-422 serial devices. In addition, the AV-HS60C3G Menu Panel is required to access and change settings locally at the switcher.
